PROGRESSIVE TRAVEL HARDTAIL
Modern geometry, a steep body kit and a solid aluminum frame with internal wiring make the SLX PRO Trail ideal for trail running, jumping or fun trail descents. This hardtail features a progressive geometry with a low top tube, plush suspension fork and dropper. Make steep climbs with a smooth ride.
IMPROVED MANEUVERABILITY
Rock Shox YARI 160mm travel fork features 15mm MaxleLite axle, Motion Control RC damper and DebonAir air spring. Sturdy and comfortable dropper KS JAG-i for smooth and consistent saddle height adjustment (125 mm). The handlebar-mounted remote lever makes it easy to operate on the go. 3D Boost 12x148mm and 66.5º head tilt provides a combination of confidence and stability at high speeds for riding on steep and difficult terrain.
BOOST TECHNOLOGY
Wider dropout spacing (110mm front / 148mm rear) results in more rigidity for added control as well as greater tire clearance and optimal drivetrain performance.
- Frame
- Aluminum 6061, double welded + polished seams, double butted, asymmetrical stays, 3D Boost 12x148mm dropouts, plug-in axle, low trail geometry, 66.5º head angle
- Fork
- Rock Shox Yari RC 29" DebonAir 160мм Motion Control
- Rear derailleur
- Shimano Deore RD-M6000-SGS, 10 speed
- Shifter
- Shimano Deore SL-M6000-R, 10 speed
- Chain
- KMC X10
- Crankset
- Prowheel MPX, crank length 170mm, 34T
- Cassete
- Microshift CS-H103, 10 speed, 11-40T
- Bottom bracket
- Prowheel BSA 73mm
- Brakes
- Shimano Deore MT501, hydraulic discs, RT-66 rotor 200/180 mm
- Rims
- DP27, tubeless shape, 32sp
- Tires
- Maxxis Rekon 29x2.4"
- Hubs
- DH906T front: 15x110 32sp, 2 sealed bearings; rear 12x148 32sp, aluminum axle, aluminum drum, 6 paws, 4 sealed bearings
- Handlebar
- KS ETHER, aluminum, ø35mm, width 780mm
- Stem
- KS ETHER, aluminum, ø35mm, length 50mm
- Seatpost
- ELEMENT, aluminum, 31.6 mm, 400 mm
- Saddle
- Selle Royal Vivo
- Pedals
- VP-536
- Box Size
- 150 x 20 x 85см
Pro Bicycle Group reserves the right to make changes to the product package.
| № | Parameter | S | M |
| 1 | Top tube length | 619mm | 643mm |
| 2 | Seat tube | 410mm | 455mm |
| 3 | Seat tube angle | 74° | 74° |
| 4 | Head tube length | 95mm | 110mm |
| 5 | Head tube angle | 66.5° | 66.5° |
| 6 | Fork offset | 46mm | 46mm |
| 7 | Chain stay length | 430mm | 430mm |
| 8 | BB Drop | 60mm | 60mm |
| 9 | Wheelbase | 1163mm | 1188mm |
| 10 | Seat tube (clamp diameter) | 34.9mm | 34.9mm |
| 11 | Seat post | 31.6mm | 31.6mm |
| 12 | Stack | 775mm | 830mm |
| 13 | Reach | 442mm | 461mm |
Pro Bicycle Group reserves the right to make changes to the product package.
