PROGRESSIVE TRAVEL HARDTAIL
Modern geometry, a steep body kit, and a durable aluminum frame with internal wiring make the SLX PRO Trail 2 the perfect piece of equipment for tackling technical trails, jumping or exciting trail descents. This hardtail features a progressive geometry with a low top tube, plush suspension fork and dropper. Make steep climbs with a smooth ride.
QUALITY COMPONENTS
Shimano Deore's 1x10 groupset and high quality aluminum wheels fitted with CST Patrol tyres, combined with the comfortable Selle Royal saddle, make the PRO Trail 2 the perfect choice for long distance rides or comfortable descents over familiar terrain.
UPDATED GEOMETRY
All-new lightweight aluminum frame with progressive geometry and low top tube. A balanced riding position gives you the perfect combination of comfort, handling and speed. Make steep climbs with a smooth ride.
NEW MODERN FRAME
The frame tubes are butted (variable tube wall thickness) to reduce weight and increase frame strength, all joined together with a double seam that is further polished for a more attractive look.
INTERNAL WIRING
All cables and hydraulic line are hidden inside the frame, which gives the bikes a more attractive and neat appearance. It also helps your wiring last longer by protecting it from dirt and moisture.
MORE CONTROL ON THE ROUTES
Wider dropout spacing (110mm front / 148mm rear) results in more rigidity. 3D Boost 12x148mm and 66.5º head angle provide a combination of confidence and stability at high speeds for steep and difficult terrain.
PLUSH FORK
X-Fusion RC32 Boost with 140mm of travel features a 15mm axle, RC Cartridge Damper and air spring. Its advantage is compression adjustment and rebound adjustment.
HYDRAULIC DROPPER
Strong and comfortable KS JAG-i dropper for smooth and consistent saddle height adjustment (125mm). A handlebar-mounted remote lever makes it easy to control on the go.
CONTROLLED BRAKING
We have equipped the CYCLONE PRO Trail 2 with Shimano MT200 hydraulic disc brakes - a guarantee of safe controlled braking even in poor conditions and on rough terrain.
UNIVERSAL TIRES
CST Patrol tires are suitable for use in various conditions. They have a versatile tread pattern with good drainage. Side studs provide good grip when cornering. The tire has improved puncture protection.
- Frame
- Aluminum 6061, double welded + polished seams, double butted, asymmetrical stays, 3D Boost 12x148mm dropouts, plug-in axle, low trail geometry, 66.5º head angle
- Fork
- X-Fusion RC32 Boost 140mm Air, tapered stem, compression adjustment, rebound adjustment, aluminum
- Rear derailleur
- Shimano Deore RD-M6000-SGS, 10 speed
- Shifter
- Shimano Deore SL-M6000-R, 10 speed
- Chain
- KMC X10
- Crankset
- Prowheel MPX, crank length 170mm, 34T
- Cassete
- Microshift CS-H103, 10 speed, 11-40T
- Bottom bracket
- Prowheel BSA 73mm
- Brakes
- Shimano MT200, hydraulic discs, 200/180 mm rotors
- Rims
- DP27, tubeless shape, 32sp
- Tires
- CST Patrol 29x2.4"
- Hubs
- SOLON DH906T front: 15x110 32sp, 2 sealed bearings; rear 12x148 32sp, aluminum axle, aluminum drum, 6 paws, 4 sealed bearings
- Handlebar
- Aluminum, ø35mm, width 700mm
- Stem
- Aluminum, ø35mm, length 70mm
- Seatpost
- ELEMENT, aluminum, 31.6 mm, 400 mm
- Saddle
- Selle Royal
- Pedals
- VP-536
- Box Size
- 150 x 20 x 85см
Pro Bicycle Group reserves the right to make changes to the product package.
| № | Parameter | S | M |
| 1 | Top tube length | 619mm | 643mm |
| 2 | Seat tube | 410mm | 455mm |
| 3 | Seat tube angle | 74° | 74° |
| 4 | Head tube length | 95mm | 110mm |
| 5 | Head tube angle | 66.5° | 66.5° |
| 6 | Fork offset | 46mm | 46mm |
| 7 | Chain stay length | 430mm | 430mm |
| 8 | BB Drop | 60mm | 60mm |
| 9 | Wheelbase | 1163mm | 1188mm |
| 10 | Seat tube (clamp diameter) | 34.9mm | 34.9mm |
| 11 | Seat post | 31.6mm | 31.6mm |
| 12 | Stack | 775mm | 830mm |
| 13 | Reach | 442mm | 461mm |
Pro Bicycle Group reserves the right to make changes to the product package.
